Description
LiftMaster LA412PKGUL Dual Solar Swing Gate Operator Kit with KPW250, (2) 811LMX, 828LM & 72" Pedestal
The LiftMaster LA412PKGUL Dual Solar Swing Gate Operator Kit with KPW250 is a complete residential solar gate automation and higher-capacity access-control package designed for entrances with two swing gate leaves. This GatePoint Solutions kit combines the LiftMaster LA412PKGUL 12VDC primary solar swing gate operator system with the LA412DCS secondary actuator, along with a LiftMaster KPW250 wireless keypad, (2) 811LMX remote controls, 828LM Internet Gateway, and GatePoint Solutions 72" in-ground gooseneck pedestal.
Built around LiftMaster's residential solar linear actuator platform, this package provides a comprehensive solution for private estates, ranch entrances, rural residences, long driveways, multi-residence properties, gated family compounds, and remote residential entrances where two gate leaves must be automated and conventional AC power may be difficult or expensive to extend to the entrance.
The LA412 platform is designed for compatible residential swing gates up to 16 ft. long or 850 lbs. per gate leaf. Its 12VDC actuator system provides smooth, controlled gate movement, while smooth start/stop operation helps reduce abrupt movement and unnecessary mechanical stress on the actuators, hinges, gate structure, and related hardware.
The included LiftMaster LA412DCS secondary actuator works with the primary LA412PKGUL system to automate the second gate leaf, creating a complete dual swing gate configuration.
Where this package really separates itself from the KPW5 version is access control. The included LiftMaster KPW250 wireless keypad supports up to 250 permanent PINs, providing substantially greater user capacity for properties where numerous residents, family members, employees, contractors, maintenance personnel, service providers, and other authorized users require gate access.
The kit also includes (2) LiftMaster 811LMX single-button remotes for convenient vehicle access and a LiftMaster 828LM Internet Gateway for compatible network connectivity with supported LiftMaster/myQ® applications.
A GatePoint Solutions 72" in-ground gooseneck pedestal completes the package by providing a professional driveway-side mounting location for the KPW250.
Together, these components create one of the most comprehensive LA412 packages in the GatePoint Solutions lineup — combining dual solar gate automation, higher-capacity wireless keypad access, vehicle remotes, compatible network connectivity, and professional pedestal mounting in one package.
What's Included
- (1) LiftMaster LA412PKGUL 12VDC Residential Solar Primary Swing Gate Operator Package
- (1) LiftMaster LA412DCS 12VDC Secondary Swing Gate Operator Actuator Arm
- (1) LiftMaster KPW250 Wireless Keypad
- (2) LiftMaster 811LMX Single-Button Remote Controls
- (1) LiftMaster 828LM Internet Gateway
- (1) GatePoint Solutions 72" In-Ground Gooseneck Pedestal
- Battery and control components supplied with the LA412PKGUL package
- Manufacturer-supplied operator mounting hardware and components
- Manufacturer-supplied safety equipment included with the LA412PKGUL package
Important: This package combines the LA412PKGUL primary operator system and LA412DCS secondary actuator to automate two compatible swing gate leaves.
Solar-system requirements vary by geographic location, available sunlight, panel placement, gate dimensions and weight, expected daily cycles, accessory loads, battery capacity, temperature, shading, and other installation conditions. The solar charging system should be properly sized for the specific installation.
LiftMaster LA412PKGUL Dual KPW250 Kit Specifications
- Primary Operator: LA412PKGUL
- Secondary Actuator: LA412DCS
- Configuration: Dual Swing Gate
- Operator Type: Residential Solar Linear Actuator
- System Voltage: 12VDC
- Application: Residential vehicular dual swing gates
- Power Application: Solar
- Maximum Gate Length: Up to 16 ft. per compatible gate leaf
- Maximum Gate Weight: Up to 850 lbs. per compatible gate leaf
- Wireless Keypad: KPW250 included
- KPW250 Capacity: Up to 250 permanent PINs
- Remote Controls: (2) 811LMX included
- Internet Gateway: 828LM included
- Pedestal: 72" in-ground gooseneck pedestal included
- Radio Technology: Security+ 2.0®
- Gate Operation: Smooth start/stop
- Obstruction Protection: Inherent reversing system
- Safety Device Support: Compatible monitored entrapment protection devices
- Manufacturer: LiftMaster
Proper gate construction, hinge condition, installation geometry, wind loading, hardware, solar exposure, battery capacity, accessory loads, expected gate cycles, and other site conditions should be evaluated when designing a dual solar swing gate system.
Why Choose This LiftMaster LA412PKGUL Dual KPW250 Kit?
This GatePoint Solutions package combines the major components needed to create a dual residential solar gate system with higher-capacity keypad access.
The LA412PKGUL primary system operates one gate leaf and provides the primary control equipment, while the included LA412DCS secondary actuator automates the second gate leaf.
This makes the system particularly useful for traditional dual driveway gates at properties where running conventional electrical service to the entrance may be impractical or expensive.
The solar-focused LA412 platform is especially attractive for:
- Private estates
- Ranch entrances
- Rural residential properties
- Long private driveways
- Gated family compounds
- Multi-residence properties
- Remote residential entrances
- Two-leaf gates located far from utility power
- Properties where trenching AC power would be costly
- Residential entrances intentionally designed around solar operation
Higher-Capacity KPW250 Access Control
The defining access-control feature of this kit is the LiftMaster KPW250 wireless keypad.
With support for up to 250 permanent PINs, the KPW250 provides substantially greater capacity than the KPW5 and makes this package better suited for properties where gate access must be provided to numerous individual users.
Potential users can include:
- Residents
- Family members
- Property managers
- Employees
- Landscapers
- Maintenance personnel
- Contractors
- Caretakers
- Service providers
- Other authorized users
This allows the customer to choose the LA412 solar platform without being limited to a basic low-user-count keypad configuration.
Dual Solar Gate Automation
Because this package includes both the LA412PKGUL and LA412DCS, it is specifically built for entrances with two swing gate leaves.
Both gate leaves become part of the same properly configured LA412 system, giving customers a purpose-built dual solar solution rather than requiring them to piece together the primary and secondary actuator equipment separately.
811LMX Wireless Vehicle Access
Two LiftMaster 811LMX single-button remote controls are included for convenient wireless vehicle access.
Additional compatible transmitters can be added separately for properties requiring more remote users.
828LM Internet Gateway Included
The included LiftMaster 828LM Internet Gateway provides compatible network connectivity for supported LiftMaster equipment and myQ applications.
The solar system and Internet Gateway perform separate functions: the LA412's solar/battery architecture provides the energy required to operate the gates, while the 828LM provides compatible network connectivity where appropriate Internet/network access is available.
Professional 72" Pedestal
The included GatePoint Solutions 72" in-ground gooseneck pedestal provides a dedicated mounting location for the KPW250 at the driveway entrance.
Its in-ground configuration allows the lower portion of the pedestal to be securely installed below grade while positioning the keypad at a practical height and location for vehicle access.
LiftMaster LA412PKGUL Dual KPW250 Kit Highlights
- Complete dual solar swing gate operator and access-control kit
- LA412PKGUL primary solar operator included
- LA412DCS secondary actuator included
- Automates two residential swing gate leaves
- 12VDC residential solar gate platform
- Supports compatible gates up to 16 ft. or 850 lbs. per gate leaf
- KPW250 wireless keypad included
- Supports up to 250 permanent PINs
- Ideal for properties requiring greater user capacity
- (2) 811LMX remotes included
- 828LM Internet Gateway included
- 72" in-ground gooseneck pedestal included
- Security+ 2.0® encrypted radio technology
- Smooth start/stop operation
- Inherent obstruction sensing
- Compatible with monitored entrapment protection equipment
- Expandable with compatible LiftMaster access-control equipment
- Excellent solution for remote, ranch, rural, estate, and long-driveway entrances
LiftMaster LA412PKGUL Dual KPW250 Kit Frequently Asked Questions
What comes with this LA412 dual solar gate operator kit?
This GatePoint Solutions package includes the LiftMaster LA412PKGUL primary solar swing gate operator system, LA412DCS secondary actuator, KPW250 wireless keypad, two 811LMX remotes, 828LM Internet Gateway, and GatePoint Solutions 72" in-ground pedestal.
It combines dual gate automation and higher-capacity access-control equipment into one residential solar gate package.
Is this kit designed for one gate or two gates?
This kit is specifically designed for a dual swing gate entrance with two gate leaves.
The LA412PKGUL provides the primary operator system, while the included LA412DCS secondary actuator operates the second gate leaf.
For a single gate leaf, choose the LiftMaster LA412PKGUL Single Solar Swing Gate Operator Kit with KPW250.
What is the LA412DCS?
The LiftMaster LA412DCS is the secondary actuator used in compatible dual LA412 installations.
It works with the primary LA412PKGUL system to automate the second gate leaf.
What size gates can the LA412 dual system operate?
The LA412 platform is designed for compatible residential swing gates up to 16 ft. long or 850 lbs. per gate leaf.
Gate construction, hinges, installation geometry, wind loading, hardware, and other site conditions must also be considered when determining operator suitability.
How many PINs does the KPW250 support?
The LiftMaster KPW250 supports up to 250 permanent PINs, making it well suited for properties where numerous authorized users require individual keypad access.
What's the difference between the KPW5 and KPW250 versions?
The primary difference is keypad user capacity.
The KPW5 is intended for residential applications requiring fewer keypad users.
The KPW250 supports up to 250 permanent PINs, making this version better suited for larger estates, multi-residence properties, ranches, gated family compounds, and properties with numerous authorized users.
The underlying LA412PKGUL + LA412DCS dual operator configuration remains the same.
Does the KPW250 require control wiring across the driveway?
The KPW250 is a wireless keypad designed for compatible LiftMaster systems, helping reduce the need for traditional control wiring between the keypad and compatible gate operator.
Installation and power requirements should follow current LiftMaster documentation.
Does a dual LA412 system require more solar capacity?
Potentially, yes.
A dual system operates two actuator arms, so its energy requirements can differ from a single-gate installation.
Solar-system sizing depends on available sunlight, geographic location, panel orientation, shading, gate dimensions and weight, daily cycles, battery capacity, accessory loads, temperature, and other site-specific factors.
Why are two 811LMX remotes included?
The included (2) LiftMaster 811LMX single-button remotes provide convenient wireless gate access for regular vehicle users.
Additional compatible transmitters can be added separately as needed.
What does the 828LM Internet Gateway do?
The included LiftMaster 828LM Internet Gateway provides network connectivity for supported LiftMaster equipment and compatible myQ applications.
Available functionality depends on connected equipment, network configuration, Internet availability, and currently supported LiftMaster services.
Can a solar gate operator still use the 828LM Internet Gateway?
Yes. Solar power and network connectivity serve separate purposes.
The LA412's solar/battery system powers the gate operator, while the 828LM provides compatible network connectivity where an appropriate network connection is available.
What is the 72" pedestal used for?
The GatePoint Solutions 72" in-ground gooseneck pedestal provides a dedicated mounting location for the KPW250 near the driveway entrance.
The lower section installs below grade while the upper gooseneck positions the keypad for convenient access from a vehicle.
Is this a good system for a ranch entrance?
Yes. The LA412 can be particularly attractive for ranch entrances, rural estates, long driveways, and remote residential gates where extending conventional electrical service to the gate could be difficult or expensive.
A properly sized solar system and adequate solar exposure are essential.
What's the difference between the LA412 Single and Dual systems?
The LA412 Single automates one swing gate leaf using the primary LA412 system.
The LA412 Dual adds the LA412DCS secondary actuator to automate a second gate leaf.
This kit is the dual configuration and includes both actuator systems.
What's the difference between the LA412 and LA400?
The LA412 is centered around 12VDC residential solar swing gate applications, while the LA400PKGUL is LiftMaster's 24VDC residential linear actuator platform.
For an entrance specifically designed around solar power, the LA412 is the more purpose-focused platform.
What's the difference between the LA412 and LA500?
The LA412 is primarily intended for residential solar swing gate applications.
The LA500 is a heavier-duty residential/light-commercial linear actuator platform intended for larger and more demanding gate applications.
Gate size, weight, construction, expected usage, wind loading, power availability, and site conditions should all be considered when selecting the appropriate operator.
Does this kit include all required safety devices?
The kit includes the components specifically listed under What's Included. Additional monitored entrapment protection devices may be required based on the gate configuration and identified entrapment zones.
Because dual swing gates may create multiple potential entrapment areas, installers should follow current LiftMaster installation documentation, applicable UL 325 requirements, local codes, and other applicable standards.
