Description
The Viking Access Systems K-2 Residential Slide Gate Operator is a compact and high-performance DC slide gate operator designed for residential driveway gates and light-duty access control applications requiring advanced diagnostics, battery backup reliability, and smooth gate operation. Engineered for residential properties, gated entrances, private estates, and low-cycle perimeter access systems, the K-2 combines intelligent controls, dependable performance, and durable construction in a compact installer-friendly platform.
Powered by a 24VDC direct-drive motor system, the Viking K-2 is capable of operating slide gates weighing up to 700 lbs. and up to 30 feet in length while maintaining smooth and quiet 12-inch-per-second gate travel. The operator features Viking’s advanced V-Flex control board platform with an integrated LCD diagnostics display, adaptive digital limits, smart positioning system, and simplified push-button programming for fast installation and troubleshooting.
The integrated V-Flex control system provides real-time system diagnostics including voltage, amperage, gate status, and operational alerts. Viking’s True Battery Backup System provides up to 100 continuous cycles during power outages while preserving battery life by preventing battery usage during normal AC-powered operation.
The K-2 also includes compatibility with Viking wireless accessory systems including Viking Konnect™ wireless communication kits and Viking Monitor™ remote management systems, allowing installers and property managers to remotely access diagnostics, settings, and operator status information from compatible devices.
Built for long-term outdoor durability, the operator includes advanced lightning protection rated up to 20,000 volts / 10,000 amps, integrated surge monitoring, a built-in heater for cold-weather operation down to -20°F, and multiple layers of corrosion protection including G90 galvanized components, zinc plating, UV-rated powder coating, and a heavy-duty steel chassis.
The Viking K-2 conforms to ANSI/CAN/UL325 safety standards and delivers dependable residential slide gate automation performance in a compact and efficient design.
Specifications:
- Model: K-2
- Product Type: Residential DC Slide Gate Operator
- Manufacturer: Viking Access Systems
- Application: Residential
- Motor Voltage: 24VDC
- Input Voltage: 120/240VAC Single Phase
- Battery Configuration: (2) 12VDC Batteries
- Battery Backup Included: Yes
- Battery Backup Capacity: Up to 100 Continuous Cycles at 700 lbs.
- Maximum Gate Weight: 700 lbs.
- Maximum Gate Length: 30 ft.
- Gate Speed: 12 in. per second
- Duty Cycle: 100% Continuous Duty
- Operating Temperature: -20°F to 160°F
- Safety Standard: ANSI/CAN/UL325 Compliant
- Control Platform: Viking V-Flex Smart Control Board
- Diagnostics Display: Integrated LCD Display
- Heater Included: Yes
- Lightning Protection: Up to 20,000V / 10,000A
- Chassis Construction: 1/4" Steel Chassis
- Corrosion Protection:
- G90 Galvanized Components
- Clear Zinc Plating
- UV-Rated Powder Coating
Key Features:
- Residential DC slide gate operator
- Handles gates up to 700 lbs. and 30 ft. long
- Advanced Viking V-Flex control board platform
- Integrated LCD diagnostics display
- Push-button digital limit programming
- Adaptive digital limits for consistent gate positioning
- Smart positioning system retains limits during power loss
- Viking True Battery Backup System included
- Up to 100 continuous backup cycles during outages
- Batteries preserved during normal AC-powered operation
- Integrated heater for cold-weather operation down to -20°F
- Advanced lightning and surge protection built in
- Plug-and-play compatibility with Viking wireless accessories
- Viking Konnect™ wireless dual-gate communication compatibility
- Viking Monitor™ remote diagnostics and monitoring compatibility
- Heavy-duty corrosion-resistant construction
- Smooth and quiet direct-drive motor operation
- Continuous-duty operation capability
- ANSI/CAN/UL325 compliant safety design
Compatible Applications:
Applications include:
- Residential driveway gates
- Private estate entrances
- HOA and gated community access
- Light-duty perimeter access systems
- Residential slide gate automation
- Battery-backed gate systems
- Cold-weather gate applications
- Smart residential access control systems
