The US Automatic Patriot RSL AC Slide Gate Operator is a high-efficiency residential and light-commercial slide gate system engineered for reliable daily operation, battery backup performance, and fast gate movement. Designed for residential properties, farms, ranches, private roads, and light-commercial applications, the Patriot RSL combines low power consumption, smooth operation, and dependable access control in a durable American-made platform.
Built specifically for slide-style gates, the Patriot RSL is capable of operating gates up to 32 feet in travel distance and weighing up to 1,000 pounds. The system features a high-efficiency inline gear motor with integrated brake assembly and delivers gate speeds up to 1 foot per second for fast and efficient entry and exit operation.
The Patriot RSL includes multi-cycle battery backup capability for continued operation during AC power outages and supports optional solar charging for off-grid or hybrid power applications. Adjustable soft start and soft stop functionality help reduce mechanical wear while improving long-term operator reliability.
Designed for simple installation and dependable operation, the Patriot RSL includes two sets of safety photo eyes and two remote controls while offering integrated timer-to-close functionality, mechanical rotary limit controls, and mobile app compatibility.
Features
Residential and light-commercial slide gate operator
Fast gate speed up to 1 foot per second
Supports gates up to 32 ft. and 1,000 lbs.
Multi-cycle battery backup operation
AC or solar charging compatible
High-efficiency inline gear motor with brake assembly
Adjustable soft start and soft stop operation
Mobile app compatible
Includes two safety photo eye sets
Includes two 2-button remote controls
Mechanical rotary limit controls
Built-in adjustable timer-to-close
Made in the USA
Specifications
Model: Patriot RSL AC Operator Type: Slide Gate Operator Gate Configuration: Single Slide Gate Applications: Residential, Light Commercial, Farm & Ranch Maximum Gate Length: 32 Ft. Maximum Gate Weight: 1,000 lbs. Power Input: 12VDC Battery / AC Drive System: Inline Gear Motor with Built-In Brake Assembly Gate Speed: 1 Ft. Per Second Limit Controls: Mechanical Adjustable Rotary Limits Soft Start/Stop: Adjustable via Pulse Width Modulation Software Timer to Close: Adjustable from 2–120 Seconds Safety Photo Eyes: Two Sets Included Remote Controls: Two 2-Button Remotes Included Receiver: Pre-Wired Solar-Friendly LCR Dual Channel Receiver Control Box Construction: Painted Galvanized Steel Frame with ABS Molded Cover Mounting Options: Concrete Pad or 4" Square Post Mount Manual Release: Pull-Knob Release Warranty: 3-Year Component / 5-Year Control Board Certifications: UL 325 Compliant – Class I, II, III & IV Country of Manufacture: United States
Key Features
High-efficiency slide gate opener platform
Continuous operation during outages with battery backup
Solar-compatible for off-grid applications
Fast gate travel speed improves property access flow
Adjustable soft start/stop extends operator life
Durable galvanized steel and ABS enclosure construction
Padlock-compatible enclosure for added security
Mobile app compatibility for convenient access management
ETL tested and UL 325 certified
Ideal for residential, ranch, and light-commercial properties
Included Accessories
One Safety Photo Eye Sets
Two 2-Button Remote Controls
Ideal Applications
Residential Driveways
Farms & Ranches
Private Roads
Light Commercial Properties
Rural Property Access
Single Slide Gate Systems
Note:Batteries, and additional access control accessories may be sold separately unless otherwise specified.
