Description
The Optex OVS-01GT Vehicle Presence Sensor is an advanced above-ground vehicle detection sensor designed for automatic gates, barrier arms, industrial doors, and parking access systems. Featuring an 18-foot detection range and dual microwave and ultrasonic sensing technology, the OVS-01GT reliably detects both moving and stationary vehicles while minimizing false detections from pedestrians. It eliminates the need for traditional in-ground loop detectors, saving installation time and avoiding costly concrete cutting.
The OVS-01GT utilizes FMCW (Frequency Modulated Continuous Wave) microwave technology to detect vehicle presence in virtually all lighting conditions, while the integrated ultrasonic sensor provides accurate close-range vehicle detection. With 8 adjustable detection patterns, 5 vehicle sensitivity settings, 5 human-cancellation settings, and one-touch calibration, installers can quickly customize detection zones for virtually any application.
Designed for fast installation, the sensor mounts above ground without disrupting traffic flow and connects directly to compatible gate operators or barrier systems without requiring additional loop detectors or programming equipment. A built-in heater and weather-resistant housing provide dependable operation in rain, snow, dust, and freezing temperatures, making it an excellent solution for residential, commercial, and industrial access control installations.
Key Features
- Genuine Optex OEM vehicle presence sensor
- Part Number: OVS-01GT
- Above-ground vehicle detection—no loop cutting required
- 18 ft (5.5 m) adjustable detection range
- Dual microwave + ultrasonic detection technology
- Detects both moving and stationary vehicles
- Ignores most pedestrian traffic
- 8 adjustable detection pattern settings
- 5 vehicle sensitivity levels
- 5 human cancellation settings
- One-touch automatic calibration
- Direct connection to gate operators and barrier systems
- Built-in heater for reliable cold-weather operation
- Easy installation with visual setup indicators
- Ideal replacement for inductive loop detectors in many applications
Ideal Applications
- Automatic slide gate operators
- Swing gate operators
- Barrier arm systems
- Industrial doors
- Parking facilities
- Commercial entrances
- Gated residential communities
- Vehicle activation and presence detection systems
Specifications
- Detection Technology: FMCW Microwave + Ultrasonic
- Detection Range: Up to 18 ft (5.5 m)
- Vehicle Speed: Approximately 2–20 km/h (1.2–12.4 mph)
- Mounting Height: Approximately 20 in. (500 mm) above ground
- Outputs: Relay output
- Built-in Heater: Yes
- Applications: Gate operators, barriers, industrial doors
- Installation: Above-ground, no concrete cutting required
