The Nice M3BAR Parking Barrier Gate Operator is a high-speed 24VDC traffic control barrier designed for parking facilities, commercial vehicle access, and public entry control applications. Engineered for fast, smooth operation and reliable continuous performance, the M3BAR is ideal for parking garages, shopping centers, hospitals, hotels, gated properties, and other high-traffic commercial environments.
Powered by a 24VDC electromechanical drive system with digital motion control, the M3BAR delivers adjustable opening and closing speeds from 1.5 to 4 seconds while supporting barrier arms from 8 to 10 feet in length. Its intelligent standby mode automatically reduces power consumption during idle periods to improve energy efficiency and long-term operational reliability.
The M3BAR features a corrosion-resistant steel cabinet, keyed mechanical release system, and elliptical aluminum arm designed to withstand wind gusts and demanding outdoor environments. Optional battery backup capability maintains operation during power outages, while integrated BlueBUS compatibility allows photo eyes to be installed directly within the cabinet for simplified installation and cleaner system integration.
Features
High-speed parking barrier gate operator
24VDC electromechanical drive system
Adjustable open/close speeds from 1.5 to 4 seconds
Supports 8 to 10 ft. barrier arms
Digital motion control for smooth operation
Intelligent standby mode reduces power consumption
Optional battery backup capability
Corrosion and oxidation-resistant steel cabinet
Keyed mechanical release for manual operation
Elliptical aluminum arm improves wind resistance
BlueBUS photo eye compatibility
Convenient top-access service design
Performance
Duty Cycle: 500 Cycles Per Hour
Open/Close Time: 1.5 to 4 Seconds
Continuous smooth digital motion control
Designed for high-traffic parking applications
Barrier Arm Configuration
Aluminum arm with red reflective striping
Optional arm lighting kits available
Optional bumper strip accessories available
Universal handing for left or right installations
Maximum Arm Length: 10 Ft.
Specifications
Model: M3BAR
Operator Type: Electromechanical Barrier Gate
Motor Voltage: 24VDC
Duty Cycle: 500 Cycles/Hour
Open/Close Speed: 1.5–4 Seconds
Maximum Arm Length: 8–10 Ft.
Handing: Universal / Field Reversible
Full Open Angle: Adjustable to 90° (87° Recommended)
Ideal Applications
Parking Garages
Shopping Centers
Hospitals
Hotels
Commercial Vehicle Access
Gated Properties
Public Traffic Control Facilities
Note:Barrier arm, lighting kits, battery backup systems, and safety accessories may be sold separately unless otherwise specified.
