Maximum Controls MAX RHINO 4000 FS Heavy-Duty Industrial Slide Gate Operator

The Maximum Controls MAX RHINO 4000 FS is a powerful, industrial-grade automatic sliding gate operator engineered for demanding, high-traffic security applications requiring exceptional gate capacity, continuous-duty performance, and fail-safe emergency accessibility. Featuring a high-torque 24V brushless DC motor, Matrix III intelligent controller, and heavy-duty Size 70 direct-drive gearbox, the MAX RHINO 4000 FS is designed to automate level sliding gates weighing up to 4,000 lbs and measuring up to 50 feet in length.

Built for industrial facilities, distribution centers, manufacturing plants, secured government installations, and restricted-access properties, the MAX RHINO 4000 FS delivers dependable performance in environments where conventional commercial slide gate operators may not provide sufficient capacity.

The operator incorporates advanced brushless motor technology with power equivalent to a 2-1/2 HP AC motor, delivering the torque required to move large, heavy industrial gates. Its direct-drive gearbox operates in an oil bath, eliminating internal belts and pulleys while reducing mechanical wear and maintenance requirements.

A defining feature of the MAX RHINO 4000 FS is its fail-safe, back-drivable design. When the operator's dynamic braking system is released through an authorized command, the gate can be manually pushed open or closed. This provides an important emergency access option during power interruptions, battery depletion, or other situations requiring manual gate movement.

The MAX RHINO 4000 FS also incorporates programmable gate speed control, built-in battery backup, adaptive obstruction detection, dynamic magnetic braking, anti-tailgating security functions, and extensive onboard diagnostics.

Its rugged industrial construction features a fully welded, 1/4-inch steel frame protected by gold zinc plating and powder coating, providing long-term durability for demanding outdoor environments.

Designed specifically for UL 325 Class III and IV vehicular gate applications, the MAX RHINO 4000 FS is an excellent solution for industrial and guarded facilities requiring powerful, dependable, and secure automated gate operation.

Key Features & Benefits

• 4,000 lb Maximum Gate Capacity: Engineered for heavy industrial sliding gates weighing up to 4,000 lbs on level installations.

• 50 ft Maximum Gate Length: Designed to accommodate large industrial vehicular sliding gates.

• Fail-Safe Back-Drivable Operation: Allows authorized manual gate movement when the operator's braking system is released.

• 24V Brushless DC Motor: High-efficiency motor delivering performance equivalent to a 2-1/2 HP AC motor.

• Continuous-Duty Operation: Designed for frequent gate cycles at demanding industrial and secured entrances.

• Heavy-Duty Size 70 Gearbox: Industrial cast iron direct-drive gearbox with a 17:1 gear ratio.

• Adjustable Gate Speed: Independently programmable opening and closing speeds, with high-speed configurations available for qualifying installations.

• Matrix III Intelligent Controller: Advanced microprocessor-based control system with adaptive motor regulation and onboard diagnostics.

• Dynamic Magnetic Braking: Helps resist unauthorized gate movement and supports controlled stopping.

• Integrated Battery Backup: Includes two 12V, 7Ah AGM batteries, with manufacturer-published backup capability of approximately 40 cycles under specified conditions.

• Programmable Virtual Limits: Electronic open and close limit programming, with optional magnetic limit sensors.

• Advanced Obstruction Detection: Intelligent electronic reversing detection with monitored safety device inputs.

• Anti-Tailgating Security: Programmable vehicle access functions for restricted industrial entrances.

• Onboard Event Logging: Stores up to 8,000 operating events and diagnostic records.

• Dual-Voltage AC Input: Selectable 115V or 230V AC single-phase electrical supply.

• Solar-Ready Power Management: Supports compatible 24V DC solar power configurations.

• Heavy-Duty #50 Drive Chain: Includes 30 feet of nickel-plated chain for industrial gate installations.

• Corrosion-Resistant Construction: Fully welded steel chassis with zinc plating and protective powder coating.

• 3-Year Limited Manufacturer Warranty: Manufacturer-backed coverage with separate battery warranty terms.

Technical Specifications

Specification	Details
Manufacturer	Maximum Controls
Model	MAX RHINO 4000 FS
Operator Type	Heavy-Duty Industrial Slide Gate Operator
Motor	24V Brushless DC
Motor Performance	2-1/2 HP AC Equivalent
Maximum Gate Weight	4,000 lbs, Level Gate
Maximum Gate Length	50 ft
Standard Published Gate Speed	12 inches per second
High-Speed Configuration	Up to 19 inches per second, subject to configuration and gate load
Duty Cycle	Continuous
Controller	Matrix III
Gearbox	Size 70 Cast Iron
Gear Ratio	17:1
Drive System	Direct Gear Drive
Manual Operation	Fail-Safe, Back-Drivable
Emergency Release	Local Switch or Compatible External Control
Input Voltage	115V / 230V AC, Single Phase
Input Current	12A at 115V / 6A at 230V
Circuit Breaker	20A
Accessory Power Outputs	12V DC and 24V DC
Limit System	Programmable Virtual Limits
Battery Backup	Two 12V, 7Ah AGM Batteries
Published Backup Capacity	Approximately 40 Cycles
Operating Temperature	-4°F to 165°F (-20°C to 74°C)
Dimensions	14.5" W × 21" D × 29" H
Published Shipping Weight	225 lbs
Drive Chain	#50 Nickel-Plated
Included Chain Length	30 ft
UL 325 Usage Classes	Class III and IV Only
Manufacturer Warranty	3 Years; Battery 1 Year

Industrial-Strength 4,000 lb Gate Capacity

The MAX RHINO 4000 FS is designed for large, heavy sliding gates that exceed the capacity of many standard commercial gate operators.

With a maximum rated gate weight of 4,000 lbs and a published maximum gate length of 50 feet, the RHINO provides the mechanical strength required for demanding industrial vehicle entrances.

Its high-torque brushless motor and heavy-duty direct-drive gearbox provide consistent gate movement while minimizing the mechanical components commonly associated with conventional belt-driven operators.

The MAX RHINO 4000 FS is particularly well suited for industrial properties where large gates must operate frequently without sacrificing reliability or security.

Important: The published 4,000 lb capacity applies to properly constructed, level, freely rolling sliding gates. The operator is not intended for uphill or downhill gate applications. Gate condition, rolling resistance, and installation geometry must be evaluated before selecting an operator.

High-Torque Brushless DC Motor & Size 70 Gearbox

The MAX RHINO 4000 FS incorporates a powerful 24V brushless DC motor with performance equivalent to a 2-1/2 HP AC motor.

Brushless motor technology eliminates conventional motor brushes, reducing mechanical wear and supporting efficient, continuous-duty operation.

The motor uses position feedback and intelligent electronic control to provide smooth acceleration, controlled deceleration, and accurate gate movement.

Maximum Controls publishes a motor design life of up to 6 million cycles under specified operating conditions.

The motor is paired with a Size 70 industrial cast iron gearbox featuring a 17:1 reduction ratio, designed for heavy-duty power transmission.

The direct-drive gearbox operates in an oil bath and eliminates internal belts and pulleys, helping reduce routine mechanical maintenance requirements.

This combination provides the power and durability needed for demanding industrial sliding gate applications.

Fail-Safe Operation & Emergency Manual Gate Release

One of the MAX RHINO 4000 FS's most important features is its fail-safe, back-drivable design.

During normal operation, the operator's dynamic braking system helps secure the gate against unauthorized movement.

When the braking system is released through an authorized command, the gate can be manually pushed open or closed without requiring normal powered operation.

Supported release methods include:

• Local manual release switch

• Compatible external keypad

• Key switch or dry-contact relay

• Compatible remote release controls, where supported and configured

This capability is particularly valuable for industrial properties requiring emergency vehicle access, maintenance access, and contingency procedures during electrical outages.

The fail-safe system works alongside the operator's integrated battery backup to provide additional options for managing gate accessibility.

Important: Fail-safe release does not mean the gate automatically opens during every power interruption. Actual behavior depends on the operator's programming, release configuration, remaining battery power, and installed access control equipment.

Adjustable Gate Speed & Intelligent Motion Control

The MAX RHINO 4000 FS features independently adjustable opening and closing speeds to accommodate the requirements of industrial gate installations.

The manufacturer's current catalog specifies a standard gate speed of 12 inches per second, while additional manufacturer documentation describes selectable high-speed operation reaching approximately 18–19 inches per second under qualifying conditions.

Programmable acceleration and deceleration help maintain smooth gate movement and reduce mechanical shock.

The Matrix III controller also provides intelligent motor regulation, obstruction detection, and controlled stopping performance.

High-speed operation should only be configured within the manufacturer's approved gate weight, safety, and installation limits.

Matrix III Intelligent Control System

The MAX RHINO 4000 FS incorporates Maximum Controls' advanced Matrix III control system, providing extensive programming and diagnostic capabilities for industrial gate installations.

The controller uses adaptive Digital Signal Processing technology to regulate brushless motor performance and monitor operating conditions.

Key functions include:

• Programmable gate opening and closing speeds

• Adjustable acceleration and deceleration

• Automatic closing timer

• Programmable partial gate opening

• Adaptive electronic reversing detection

• Primary and secondary operator coordination

• Anti-tailgating security functions

• Gate disable and tamper monitoring

• Gate position and status outputs

• Magnetic lock control

• Integrated LCD diagnostic display

• Event history logging for up to 8,000 events

These capabilities allow installers to configure the operator for demanding industrial security applications while providing valuable diagnostic information for ongoing maintenance and troubleshooting.

Integrated Battery Backup & Power Management

The MAX RHINO 4000 FS includes an integrated battery backup system utilizing two 12V, 7Ah AGM batteries.

Maximum Controls publishes approximately 40 backup cycles under specified conditions, although actual operating cycles depend on gate weight, gate length, battery condition, temperature, and mechanical resistance.

When normal AC power is available, the operator does not rely on battery power for routine gate movement.

Additional electrical capabilities include:

• Switchable 115V / 230V AC single-phase input

• Built-in 12V DC and 24V DC accessory power outputs

• Compatible 24V DC solar input

• Intelligent energy-saving power management

• Motor overcurrent safety protection

• Advanced lightning and surge protection

• Programmable power-loss operation

These features support industrial installations requiring dependable power management and emergency operation.

Industrial Security & Anti-Tamper Protection

The MAX RHINO 4000 FS incorporates advanced security functions designed for restricted-access industrial entrances.

Dynamic Magnetic Braking: Helps resist unauthorized attempts to push the gate open while the operator is secured.

Tamper Detection: Audible alarms and relay outputs can provide notification of attempted unauthorized gate movement.

Anti-Tailgating Functionality: Programmable vehicle access controls help manage unauthorized entry behind approved vehicles.

Gate Status Monitoring: Dedicated outputs provide gate position information for compatible security and monitoring systems.

Optional Chain-Drop Detection: Compatible chain monitoring equipment can detect chain disengagement and trigger configured alarms.

Lockable Steel Cover: Helps restrict unauthorized access to the operator's internal controls and mechanical components.

Programmable Partial Opening: Allows authorized access configurations without requiring the gate to travel its full distance for every operation.

These features make the RHINO 4000 FS suitable for industrial properties requiring both reliable vehicle access and enhanced perimeter security.

UL 325 Class III & IV Safety Requirements

The MAX RHINO 4000 FS is intended for UL 325 Class III and Class IV vehicular sliding gate applications only.

Class III applications generally include industrial locations such as factories, warehouses, and loading facilities where access is restricted from the general public.

Class IV applications include guarded or restricted-access facilities where entry is controlled by security personnel.

The operator incorporates inherent electronic reversing detection and supports monitored external entrapment protection devices.

Two monitored entrapment protection sensors are required, with one protecting each direction of gate travel, according to the manufacturer's installation manual.

Compatible devices include appropriately configured monitored photoelectric sensors and sensing edges.

The MAX RHINO 4000 FS is not intended for Class I residential or Class II general-access commercial installations.

Ideal Applications

The Maximum Controls MAX RHINO 4000 FS is an excellent choice for:

• Industrial manufacturing plants

• Distribution centers and freight terminals

• Heavy equipment yards

• Secured warehouses and logistics facilities

• Industrial storage and transportation yards

• Government and military installations

• Guarded industrial entrances

• Airports and restricted-access facilities

• Large industrial sliding gates requiring emergency manual release

• High-traffic industrial entrances requiring continuous-duty operation

Standard Equipment & Optional Accessories

Manufacturer-Listed Standard Equipment:

• Maximum Controls MAX RHINO 4000 FS Slide Gate Operator

• Matrix III intelligent control system

• Heavy-duty Size 70 direct-drive gearbox

• Lockable metal operator cover

• Integrated battery backup system with two 12V, 7Ah AGM batteries

• 30 ft of #50 nickel-plated drive chain

• Programmable virtual limit system

• Local emergency release capability

Optional Accessories (Sold Separately):

• Magnetic limit sensors

• Compatible monitored photoelectric safety sensors

• Monitored safety edge systems

• Vehicle loop detectors

• Industrial access control keypads and readers

• Compatible chain tray

• Optional chain-drop detection system

• Compatible solar power accessories

• Remote monitoring and access control equipment

Installation Note: The MAX RHINO 4000 FS is designed exclusively for Class III and IV vehicular sliding gate applications. It must be installed on a properly constructed, level, freely moving gate using the required monitored entrapment protection devices. Installation should be performed by qualified gate automation professionals in accordance with Maximum Controls' installation instructions and applicable safety standards.

Warranty: Maximum Controls provides a 3-year limited manufacturer warranty on the operator and a separate 1-year battery warranty. Refer to the manufacturer's current warranty documentation for complete terms and exclusions.
