Description
The Linear ACT-31B is a compact 1-channel MegaCode® key ring transmitter designed for secure operation with Linear access control receivers and controllers. This block-coded transmitter provides dependable wireless access control while helping prevent unauthorized duplication through factory-programmed MegaCode technology.
Each ACT-31B transmitter is pre-programmed with one of over 1,000,000 unique MegaCode combinations, providing enhanced security and virtually eliminating code duplication concerns. The receiver learns each individual transmitter code, preventing unauthorized access attempts through reprogrammed remotes.
This block-coded version is factory programmed in sequential transmitter ID blocks, allowing easy enrollment into compatible Linear access control systems by entering the first and last transmitter codes from the block. Facility codes may also be selected to further customize system operation.
This package includes 10 transmitters.
Key Features
- 1-channel key ring transmitter
- MegaCode® format with over 1,000,000 possible codes
- Block-coded for simplified system enrollment
- Compatible with Linear access receivers and controllers
- Factory-programmed sequential transmitter ID codes
- Quick-disconnect key ring included
- 10-second transmission timeout protection
- Compact and lightweight design
- Long battery life for dependable operation
Technical Specifications
- Model: ACT-31B
- Frequency: 318 MHz
- Channels: 1
- Technology: MegaCode®
- Power Source: Two CR2016 lithium batteries
- Dimensions: 1.25" W x 2.25" H x 0.48" D
- Color: Black
- Part Number: ACP00879
Benefits
- Helps prevent unauthorized code duplication
- Secure access control credential management
- Easy deployment of multiple transmitters
- Long-lasting battery performance
- Compact keychain-friendly design
- Ideal for gates, barriers, doors, and access control systems
Common Applications
- Automatic gate operators
- Access control systems
- Parking facilities
- Gated communities
- Commercial properties
- Industrial facilities
- Controlled-entry doors
Package Includes
- 10 × Linear ACT-31B 1-Channel Block-Coded Key Ring Transmitters
- Quick-disconnect key rings
- Pre-installed batteries
Compatibility
Compatible with Linear MegaCode® access control receivers, controllers, gate operators, and other supported Linear wireless access systems operating on 318 MHz technology.
Note: This listing is for a box of 10 Linear ACT-31B block-coded transmitters. Transmitters are factory-programmed with sequential transmitter ID codes for simplified enrollment into compatible Linear access control systems.
