Description
Meet the LiftMaster CSW200101UL, a heavy-duty 1HP AC commercial swing gate operator designed for high-cycle, security-focused entrances. Built for institutional, commercial, and multi-site installations, it delivers reliable, scalable perimeter control with enterprise-grade connectivity.
- Motor & Duty: 1 HP continuous-duty AC motor engineered for constant operation in busy, high-traffic environments.
- Transmission: Dual oil-bath wormgear gearboxes providing 900:1 total reduction for smooth, consistent torque and long-term durability.
- Smart Connectivity: Integrated myQ technology enables remote monitoring, status alerts, and centralized control across multiple sites.
- Security & Safety: UL-listed system with Security+ 2.0 encrypted radio, enhanced safety architecture, and monitored entrapment protection.
- Dual-Gate Synchronization: Wireless wireless synchronization for dual-leaf gates with synchronized close—no trenching required.
- Emergency & Detection Aids: Emergency manual disconnect with limit-position retention and inherent reversing sensor for obstruction protection.
- Safety Equipment: LMRRUL Monitored Retroreflective Photo Eye with up to 50 ft range and a wide polarized beam for reliable sensing.
- Power & Controls: 115V single-phase input; 24VDC 500mA accessory output; optional 3-Phase Conversion Kit (208/240/460/575 VAC → 115 VAC).
- Construction: 1/4" gold-zinc-plated steel chassis; two-piece high-density UV-resistant polyethylene cover; built for corrosion resistance and long service life.
- Environment & Climate: Operates without heater from -4°F to 140°F (-20°C to 60°C); with optional heater down to -40°F (-40°C).
- Performance: 90° gate opening in 13–15 seconds; pre-motion warning alarm; bi-part delay sequencing; mechanical limit positioning; LED diagnostic display.
- Remotes & Access Management: Supports up to 50 remotes via Security+ 2.0 onboard receiver (expandable to unlimited).
- Warranty & Compliance: 5-year commercial / 7-year residential warranty; UL Listed with monitored safety devices.
- Physical Footprint: CSW200101UL dimensions: 27.99" H × 15.20" W × 24.75" D; approximate weight 175 lbs.
The CSW200101UL stands out in demanding environments where uptime, safety, and centralized control matter. Its gear-driven reliability reduces maintenance intervals, while the integrated smart infrastructure supports remote oversight, multi-site management, and seamless integration with enterprise access platforms. Designed for easy retrofits or new installations, it enables single- or dual-leaf configurations with robust safety, encrypted communications, and a durable build that withstands harsh conditions and high usage. Optional heater broadens operational reliability in extreme climates, ensuring access control remains uninterrupted year-round. With extensive safety features and a comprehensive warranty, this LiftMaster solution is built to protect people and property while simplifying perimeter management across locations.
