Description
The EMX PTM-120 120 VAC Programmable Timer is a professional-grade 7-day digital timer designed to automate the opening and closing schedules of automatic gates, overhead doors, parking barriers, lighting systems, and other access control equipment. Powered by 120 VAC, the PTM-120 offers flexible scheduling with up to 16 ON/OFF events per day and 15 programmable daily schedule combinations, making it an ideal solution for facilities requiring secure, automated access.
Featuring a compact DIN rail mount design, the PTM-120 installs easily inside control enclosures and includes an internal battery backup that preserves programming during power outages. Users can select either a 12-hour or 24-hour clock format, while the large LCD display and intuitive push-button interface simplify programming and daily operation. The PTM-120 also helps reduce unnecessary gate cycling, minimizing wear on operator motors and extending the life of automated equipment.
Key Features
- Genuine EMX Industries OEM programmable timer
- Part Number: PTM-120
- Operates on 120 VAC
- Easy-to-program 7-day digital timer
- Up to 16 programmable ON/OFF events per day
- 15 daily scheduling combinations
- SPDT relay rated at 16A @ 24 VDC / 120 VAC
- Large LCD display with simple push-button programming
- DIN rail mount for quick installation
- Internal battery backup preserves programming during power outages
- Selectable 12-hour or 24-hour clock format
- Helps reduce wear and tear on gate operators, overhead doors, and parking barriers by automating operating schedules.
Ideal Applications
- Automatic gate operators
- Parking barrier systems
- Overhead and roll-up doors
- Commercial and industrial facilities
- HOA and gated communities
- Warehouses and distribution centers
- Lighting and equipment scheduling
Specifications
- Input Voltage: 120 VAC
- Programming: 16 ON/OFF events per day
- Daily Programs: 15 schedule combinations
- Relay Rating: SPDT 16A @ 24 VDC / 120 VAC
- Mounting: DIN Rail
- Operating Temperature: 14°F to 122°F (-10°C to 50°C)
- Memory Backup: Up to 90 days
- Housing: ABS Plastic
