Description
The EMX PTM-12 12 VDC/AC Programmable Timer is a professional-grade 7-day digital timer designed to automate the operation of automatic gates, overhead doors, parking barriers, and access control systems powered by 12 VDC or 12 VAC. Featuring flexible scheduling with up to 16 programmable ON/OFF events per day and 15 daily program combinations, the PTM-12 provides secure, reliable access control for residential, commercial, and industrial applications.
Designed for quick installation, the PTM-12 mounts on a standard DIN rail and features a large LCD display with intuitive push-button programming. An internal battery backup preserves programmed schedules during power outages, while selectable 12-hour or 24-hour clock formats provide added flexibility. By automating scheduled opening and closing times, the PTM-12 helps reduce unnecessary cycling, extending the life of gate operators and other automated equipment.
Key Features
- Genuine EMX Industries OEM programmable timer
- Part Number: PTM-12
- Operates on 12 VDC or 12 VAC
- Easy-to-program 7-day digital timer
- Up to 16 programmable ON/OFF events per day
- 15 daily scheduling combinations
- SPDT relay rated at 16A @ 24 VDC / 120 VAC
- Large LCD display with simple push-button programming
- DIN rail mount for quick installation
- Internal battery backup retains schedules during power outages (up to 90 days)
- Selectable 12-hour or 24-hour clock format
- Helps reduce wear on gate operators, parking barriers, and overhead doors through automated scheduling.
Ideal Applications
- Automatic gate operators
- Parking barrier systems
- Overhead and roll-up doors
- Commercial access control systems
- HOA and gated communities
- Warehouses and industrial facilities
- Timed lighting and equipment control
Specifications
- Input Voltage: 12 VDC/AC
- Programming: 16 ON/OFF events per day
- Daily Programs: 15 schedule combinations
- Relay Rating: SPDT 16A @ 24 VDC / 120 VAC
- Mounting: DIN Rail
- Operating Temperature: 14°F to 122°F (-10°C to 50°C)
- Memory Backup: Up to 90 days
- Housing: ABS Plastic
