Description
The DoorKing 9050-381 is a residential slide gate operator engineered for secure, dependable operation in single-family residential applications. Built on the proven 9050 platform, this model features a rugged galvanized steel chassis, durable metal cover, and a fail-secure release system that keeps the gate locked during power outages for applications where security is a priority.
Featuring a 1/2 HP AC motor, self-adjusting magnetic limit technology, and a quiet belt-drive system, the 9050-381 delivers smooth operation, simplified installation, and long-term reliability. Its compact footprint and versatile mounting options make it an excellent choice for homeowners seeking professional-grade access control performance.
Performance & Application
Designed for residential slide gates up to 20 feet in length and 700 pounds, the 9050-381 provides fast gate travel speeds of approximately 10 inches per second while maintaining quiet operation. The operator's self-adjusting magnetic limits eliminate traditional mechanical limit switches that can wear over time, reducing maintenance requirements and improving reliability.
Unlike the standard fail-safe configuration, the 9050-381 incorporates a fail-secure release mechanism that maintains gate security during power loss conditions. This makes it particularly well-suited for residential properties where controlled access and perimeter security are important considerations.
The operator includes programmable control functions, adjustable auto-close settings, plug-in loop detector compatibility, integrated convenience outlets, and Gate Tracker™ reporting capability for expanded system monitoring and access control integration.
Key Features
• 115 VAC residential slide gate operator
• Heavy-duty metal cover construction
• Fail-secure release system
• 1/2 HP limited-duty AC motor
• Self-adjusting magnetic limit technology
• Supports gates up to 20 ft. long
• Supports gates up to 700 lbs.
• Quiet belt-driven operation
• Approximate speed of 10 in./sec.
• Built-in power switch
• Built-in alarm reset switch
• Adjustable auto-close timer
• Programmable operating modes
• Plug-in loop detector ports
• Selectable stop/reverse loop functions
• Two convenience outlets for accessories
• Pad mount or post mount installation
• Galvanized steel frame resists corrosion
• Gate Tracker™ reporting capability
• ETL Listed
• UL 325 and UL 991 compliant
Ideal Applications
• Residential driveway gates
• Estate entrances
• Luxury homes
• Private residential roadways
• Ranch and farm entrances
• Security-focused residential properties
• Gated residential access points
• Homeowner association private entrances
Specifications
Model: 9050-381
Operator Type: Residential Slide Gate Operator
Motor: 1/2 HP Limited-Duty AC Motor
Input Voltage: 115 VAC, 60 Hz
Current Draw: 5.4 Amps
Maximum Gate Length: 20 ft.
Maximum Gate Weight: 700 lbs.
Gate Speed: Approximately 10 in./sec.
Drive System: Single Cog Belt Drive
Class of Operation: Class I
Release Type: Fail-Secure Release
Frame Construction: G90 Galvanized Steel
Cover Type: Metal Cover
Operating Temperature: 10°F to 140°F
Compliance: UL 325 and UL 991
Certification: ETL Listed
Dimensions: 12"W x 24"H x 11.5"D
Shipping Weight: Approximately 70 lbs.
What's Included
• DoorKing 9050-381 Residential Slide Gate Operator
• Poly Protective Cover
• Integrated Control Board
• Fail-Secure Release Assembly
• 20 Ft. #40 Roller Chain
• Chain Brackets and Mounting Hardware
• Installation Documentation
