Description
The DoorKing 6524-381 is a 24 VDC solar-powered swing gate operator engineered for locations where AC power is unavailable or impractical. Designed specifically for off-grid installations, the 6524-381 operates exclusively from a 24 VDC solar power system, making it an excellent choice for ranches, farms, private roads, remote properties, gated communities, and commercial entrances. Its efficient DC motor, quiet belt-drive system, and advanced electronic controls deliver dependable gate automation while minimizing power consumption.
Powered by a 1/2 HP Quadra Drive™ DC motor, the 6524-381 is capable of operating swing gates up to 16 feet in length and 800 pounds. The operator features a durable belt-drive 60:1 worm gear reduction system for smooth, quiet operation, while built-in batteries store solar energy to provide reliable gate cycles during periods of low sunlight. Its compact design, split housing for simplified servicing, electronic magnetic limits, and programmable microprocessor controller make installation and long-term maintenance straightforward.
The DoorKing 6524-381 integrates seamlessly with DoorKing telephone entry systems, keypads, card readers, RF transmitters, loop detectors, and monitored safety devices to create a complete solar-powered access control solution. Soft start and soft stop operation reduce wear on both the operator and gate hardware, while compliance with UL 325 safety requirements helps ensure safe operation when installed with the required monitored entrapment protection devices.
Key Features
- Genuine DoorKing 6524-381 DC swing gate operator
- Solar-ready 24 VDC operation
- 1/2 HP Quadra Drive™ DC motor
- Built for off-grid installations
- Quiet belt-drive reduction system
- Supports gates up to 16 ft. long
- Supports gates up to 800 lbs.
- Built-in rechargeable battery system
- Electronic magnetic limits
- Soft start and soft stop operation
- Advanced programmable microprocessor controller
- Compatible with DoorKing keypads, telephone entry systems, card readers, RF transmitters, loop detectors, and monitored safety devices
- UL 325 compliant when installed with required monitored safety devices
Ideal Applications
The DoorKing 6524-381 is ideal for:
- Remote residential properties
- Farms and ranches
- Private roads
- Gated communities
- Commercial entrances
- Rural facilities
- Utility sites
- Agricultural properties
- Off-grid installations
- Solar-powered access control systems
Specifications
- Manufacturer: DoorKing
- Model: 6524-381
- Operator Type: Solar-Powered DC Swing Gate Operator
- Motor: 24 VDC 1/2 HP Quadra Drive™
- Drive System: Belt Drive
- Maximum Gate Length: 16 ft.
- Maximum Gate Weight: 800 lbs.
- Power Input: 24 VDC Solar Only
- Battery Backup: Built-in rechargeable batteries
- Application Classes: UL Class I, II, III & IV
- Solar Compatible: Dedicated solar-powered model
