Description
The DoorKing 6300-384 is a heavy-duty commercial and industrial swing gate operator engineered for demanding applications requiring maximum performance and long-term reliability. Equipped with a 1 HP continuous-duty motor, the 6300-384 is designed to automate larger, heavier swing gates while delivering the smooth operation and durability DoorKing is known for. It is ideal for commercial facilities, industrial sites, gated communities, apartment complexes, and other high-cycle installations.
Designed for flexibility, the 6300 Series can be ordered in either pad-mount or post-mount configurations, allowing installers to choose the best solution for the application. Its unique bottom-rail gate arm design provides dependable gate movement while simplifying installation and long-term maintenance. The 6300-384 accommodates gates up to 22 feet in length and 800 pounds, making it an excellent choice for demanding vehicular access applications.
The DoorKing 6300-384 integrates seamlessly with DoorKing telephone entry systems, access control devices, transmitters, keypads, card readers, loop detectors, and monitored safety equipment to create a complete automated entrance solution. When installed with the required monitored entrapment protection devices, the operator complies with current UL 325 safety requirements.
Key Features
- Genuine DoorKing 6300-384 swing gate operator
- Heavy-duty commercial and industrial design
- 1 HP continuous-duty AC motor
- Available in pad-mount or post-mount configurations
- Supports gates up to 22 ft. long
- Supports gates up to 800 lbs.
- Opens approximately 90° in 15–18 seconds
- Bottom-rail gate arm design
- Compatible with DoorKing access control systems
- Supports keypads, telephone entry systems, card readers, transmitters, loop detectors, and monitored safety devices
- UL 325 and UL 991 compliant when installed with the required safety devices
Ideal Applications
The DoorKing 6300-384 is ideal for:
- Industrial facilities
- Manufacturing plants
- Distribution centers
- Commercial properties
- Apartment complexes
- Gated communities
- Self-storage facilities
- Farms and ranches
- Government facilities
- High-cycle vehicular entrances
Specifications
- Manufacturer: DoorKing
- Model: 6300-384
- Operator Type: Swing Gate Operator
- Motor: 1 HP Continuous-Duty
- Maximum Gate Length: 22 ft.
- Maximum Gate Weight: 800 lbs.
- Opening Speed: Approximately 15–18 seconds to 90°
- Available Voltages: 115, 230, or 460 VAC (configuration dependent)
- Application Classes: UL Class I, II, III & IV
- Mounting Options: Pad Mount or Post Mount
