Description
The CellGate E4VZN Entría Four-Door Controller is a cloud-managed access control solution designed to control up to four doors, gates, or entry points using Verizon cellular LTE connectivity. It is an excellent solution for commercial facilities, multifamily properties, gated communities, and other locations where running wired internet to the access controller is impractical or cost-prohibitive.
The E4VZN features four 26-bit Wiegand reader inputs and integrates with CellGate readers as well as compatible third-party 26-bit Wiegand devices. Individual credential restrictions can be assigned by entry point, with restricted credential information stored locally on the controller.
The cellular version also supports integration with up to four external cameras, providing enhanced visual verification at access points. System administration is handled remotely through CellGate's cloud-based TrueCloud Connect platform.
Key Features:
- Controls up to 4 doors, gates, or entry points
- Verizon cellular LTE connectivity
- (4) 26-bit Wiegand reader inputs
- (8) programmable relay outputs
- (4) digital inputs
- (4) REX (Request-to-Exit) inputs
- Compatible with CellGate readers
- Works with compatible third-party 26-bit Wiegand readers
- Individual credential restrictions by entry point
- Restricted credentials stored locally
- Supports up to 4 external cameras on cellular models
- Remote administration through TrueCloud Connect
- CellGate app integration
- Fire alarm functionality
- NEMA 3-rated enclosure
- 12V DC power
- Suitable for indoor and outdoor installations
Manufacturer: CellGate
Part Number: E4VZN
Product Family: Entría E4DC
Entry Points: Up to 4
Connectivity: Verizon Cellular LTE
Reader Inputs: (4) 26-bit Wiegand
Relay Outputs: (8) Programmable
Power: 12V DC
Enclosure: NEMA 3
Important: The E4VZN requires a monthly recurring service charge for ongoing CellGate app and TrueCloud Connect functionality, transaction/photo storage, and cellular data transmission.
