Description
The CellGate E4ETH Entría Four-Door Controller is a cloud-managed access control solution designed to control up to four doors, gates, or entry points using a wired Ethernet connection. Built for commercial, multifamily, gated community, and other multi-entry applications, the E4ETH provides centralized access management through CellGate's TrueCloud Connect platform and CellGate app.
The E4ETH features four 26-bit Wiegand inputs, allowing it to integrate with CellGate readers or compatible third-party 26-bit Wiegand readers. Each entry point can have individual credential restrictions, while credentials are stored locally on the controller to help maintain access functionality if network connectivity is interrupted.
For enhanced site monitoring, the wired Ethernet model supports integration with up to three external cameras. An optional CellGate SurePath upgrade can also provide automatic Ethernet-to-cellular LTE failover for additional communication redundancy.
Key Features:
- Controls up to 4 doors, gates, or entry points
- Wired Ethernet connectivity
- (4) 26-bit Wiegand reader inputs
- (8) programmable relay outputs
- (4) digital inputs
- (4) REX (Request-to-Exit) inputs
- Compatible with CellGate readers
- Compatible with third-party 26-bit Wiegand readers
- Supports individual credential restrictions by entry point
- Credentials stored locally on the controller
- Supports up to 3 external cameras on Ethernet
- Optional SurePath Ethernet-to-cellular LTE failover
- Remote management through TrueCloud Connect
- CellGate app support for remote gate and door control
- NEMA 3-rated enclosure
- 12VDC power
- Suitable for indoor and outdoor installations
Manufacturer: CellGate
Part Number: E4ETH
Product Family: Entría E4DC
Entry Points: Up to 4
Connectivity: Wired Ethernet
Reader Inputs: (4) 26-bit Wiegand
Relay Outputs: 8 Programmable
Power: 12VDC
Enclosure: NEMA 3
What's Included:
- (1) CellGate Entría Four-Door Controller
- (1) 12V / 5A Power Supply
- Customer Information Packet
Important: CellGate Entría products require a monthly recurring service charge for continued use of TrueCloud Connect, CellGate app services, transaction/photo storage, and access-control data transmission.
