Description
The Cartell CW-SYS Wireless Driveway & Free Exit System delivers dependable wireless vehicle detection for residential, commercial, agricultural, and gated property applications. Utilizing proven magnetometer sensing technology, the CW-SYS detects moving metal vehicles while ignoring motion, animals, weather, and pressure changes, providing reliable performance with virtually no false alarms.
Designed for installers and property owners seeking a trench-free solution, the CW-SYS eliminates the need for underground wiring while providing seamless integration with virtually all major automatic gate operators. The system includes a wireless sensor puck and receiver/integrator module that communicate wirelessly over distances up to 1,000 feet line-of-sight, making it ideal for long driveways and remote gate installations.
The self-contained sensor operates on long-life CR123A batteries and installs quickly without trenching, conduit, or extensive wiring. Adjustable sensitivity settings allow installers to optimize detection performance for specific site conditions, while the rugged IP68-rated enclosure ensures reliable operation in harsh outdoor environments.
Whether used for free-exit gate automation, driveway vehicle alerts, or integrated property access control, the CW-SYS provides a simple, dependable, and professional-grade wireless detection solution.
Key Features
- Wireless vehicle detection and free-exit system
- Advanced magnetometer sensing technology
- Detects moving metal vehicles only
- No trenching or underground wiring required
- Wireless communication up to 1,000 ft line-of-sight
- Adjustable sensitivity settings
- Compatible with most gate operators and access systems
- Battery-powered sensor puck
- IP68-rated sensor enclosure
- Includes receiver/integrator module
- Low-battery monitoring capability
- Fast installation typically under one hour
Benefits
- Eliminates costly trenching and conduit installation
- Reduces installation time and labor costs
- Reliable vehicle detection with minimal false alarms
- Perfect for long driveways and remote gate locations
- Works with new installations and retrofit projects
- Long battery life for reduced maintenance
- Weather-resistant construction for year-round operation
- Flexible integration with access control systems
- Easy setup and configuration
Applications
- Automatic gate free-exit systems
- Residential driveway alerts
- Ranch and farm entrances
- Private roads and gated communities
- Commercial property access
- Industrial facility entrances
- Remote gate installations
- Security and vehicle monitoring systems
What's Included
- Wireless Sensor Puck
- Integrator / Receiver Module
- (2) Auger Mounting Screws
- (2) CR123A Batteries
- Sensor Screwdriver
- Installation Documentation
Specifications
- Model: CW-SYS
- Detection Technology: Magnetometer Vehicle Detection
- Wireless Range: Up to 1,000 ft (305 m) line-of-sight
- Sensor Power: 2 × CR123A Batteries
- Sensor Battery Life: 1–3 Years
- Sensor Standby Current: 22 µA
- Integrator Power: 8–24 VAC or 8–30 VDC
- Relay Contacts: SPDT, N.O. or N.C. (Form C)
- Relay Contact Rating: 2 Amp @ 24 VDC
- Relay Time: 2 Seconds
- Sensor Enclosure Rating: IP68
- Sensor Strength Rating: 9.39 Ton Force (8513 kgf)
- Operating Temperature: -25°F to 140°F (-32°C to 60°C)
- Warranty: 3 Years
Why Choose the Cartell CW-SYS?
The Cartell CW-SYS combines industry-leading magnetometer vehicle detection with wireless convenience, providing installers and property owners with a dependable, trench-free solution for driveway monitoring and automatic gate free-exit control. Its rugged construction, long battery life, and simple installation make it one of the most versatile vehicle detection systems available.
