Description
The AWID XK-3640 is a gray, all-in-one UHF switchplate-type reader with an integrated 12-key keypad, designed to streamline access control for doors and turnstiles. It delivers a compact, stylish solution that works with AWID’s long-range readers and credentials for upscale environments and harsh conditions alike.
- All-in-one design: Card reader and 12-key keypad are combined into a single surface-mounted unit for simplified installation and operation.
- Long-range read performance: Up to 6 inches read distance on walls or metal surfaces, ensuring reliable, single-card reads in high-traffic areas.
- Interfaces and data formats: Card reader outputs both Wiegand and RS-232; keypad outputs Wiegand only; supports 26- to 50-bit codes programmed into AWID UHF credentials.
- Connectivity and wiring: Includes an integrated 18-inch shielded cable with 10 conductors for power and data; 22 AWG, 4-wire subset for Wiegand; shielded with a gray jacket; Wiegand runs up to 500 feet.
- Power and durability: Powered from +5 to +12 VDC at 1 A or more; rugged ABS 2-part enclosure with RoHS-compliant materials and a gray cable jacket for mixed environments.
- Physical design and mounting: Compact footprint (3.1 x 4.9 x 1.0 inches); weighs 8 ounces; mounts on single-gang boxes or on-wall for versatile installation.
- Environment and reliability: Operational from -31°F to 150°F (-35°C to 65°C) with 0–95% non-condensing humidity; suitable for indoor and outdoor access points.
- User feedback: Built-in 2-color LED and audible beeper provide immediate read and keypad-entry feedback for users and administrators.
- Compatibility and ecosystem: Designed to work with AWID’s long-range readers using the same credentials, allowing seamless integration into existing access control software.
- Security and two-factor access: Combines card-based access with keypad entry for added security, traceability, and flexible authentication options.
The XK-3640 is ideal for elegant entrances in residential complexes or rugged entrances in industrial facilities where two-factor, high-volume access is essential. Its all-in-one form reduces installation complexity, while the 6-inch read range and configurable credential bits support reliable performance in crowded or challenging environments. By staying compatible with AWID’s long-range readers and using the same credentials, it simplifies deployment and ongoing management, delivering a clear, secure, and scalable access control solution for both new builds and facility upgrades.
