Description
The AWID LR-3200 is a long-range UHF RFID reader designed for Automatic Vehicle Identification (AVI), parking management, and access control applications throughout regions utilizing the European UHF RFID frequency band. Operating within the 865–868 MHz frequency range, the LR-3200 delivers dependable long-range credential reading while providing seamless integration with access control systems, parking facilities, and secure perimeter applications.
Built with an integrated RHCP patch antenna and rugged IP65-rated enclosure, the LR-3200 combines reader electronics and antenna technology into a single compact unit for simplified installation and reliable outdoor performance. The reader supports passive RFID credentials, eliminating the need for batteries while providing read ranges of up to 25 feet.
The LR-3200 features simultaneous Wiegand and RS-232 outputs, allowing compatibility with a wide range of access control systems and vehicle management platforms. AWID's proprietary encrypted communication technology helps ensure secure credential transactions between the reader and authorized RFID cards or vehicle tags.
Key Features
- Long-range UHF RFID reader
- European frequency operation (865–868 MHz)
- Read ranges up to 25 feet
- Integrated RHCP patch antenna
- Simultaneous Wiegand and RS-232 outputs
- Supports passive RFID credentials
- Programmable repetition rate for optimized performance
- Weather-resistant IP65-rated enclosure
- Designed for outdoor installations
- ETSI compliant
Benefits
- Ideal for Automatic Vehicle Identification (AVI)
- Reliable long-range credential reading
- Simplified installation with integrated antenna
- Compatible with standard access control systems
- Cost-effective passive RFID credential solution
- No batteries required in RFID credentials
- Secure encrypted communications
- Suitable for parking and perimeter security applications
Applications
- Vehicle access control
- Parking management systems
- Gated communities
- Commercial and industrial facilities
- Campus and institutional security
- Hospital vehicle access systems
- Automated gate entry systems
- Secure perimeter management
Specifications
- Model: LR-3200
- Manufacturer: AWID
- Technology: UHF RFID
- Frequency Range: 865 MHz – 868 MHz (FHSS)
- RF Power Output: 1 Watt (30 dBm)
- Read Range: Up to 25 Feet
- Antenna: Integrated RHCP Patch Antenna
- Interface: Wiegand and RS-232 (Simultaneous)
- Dimensions: 9.8" x 9.8" x 1.3"
- Protection Rating: IP65
- Compliance: ETSI EN302 208 V3.1.1, RED 2014/53/EU
- Credential Compatibility: AWID UHF Cards and Tags
Meta Description:
AWID LR-3200 long-range UHF RFID reader operating at 865–868 MHz. Features up to 25-foot read range, integrated antenna, Wiegand and RS-232 outputs, and IP65-rated housing for vehicle and access control applications.
