Description
The All-O-Matic SL-175DC PRO is an ultra heavy-duty commercial and industrial DC slide gate operator engineered for extreme-duty perimeter access control applications requiring maximum gate capacity, continuous-duty performance, and advanced brushless DC technology. Designed for industrial facilities, transportation yards, warehouses, distribution centers, utility sites, commercial compounds, gated communities, and high-security perimeter applications, the SL-175DC PRO delivers exceptional power, durability, and operational reliability for the most demanding installations.
The SL-175DC PRO features an all-new super-duty high-strength frame, heavy-duty gearbox assembly, and an upgraded 36VDC brushless motor platform designed for smooth, quiet, high-torque operation with virtually zero routine motor maintenance. The operator is capable of handling gates weighing up to 8,000 lbs. at 12 inches per second or gates up to 3,000 lbs. at 24 inches per second, with maximum gate lengths up to 100 feet.
Engineered around All-O-Matic’s advanced ALL-BLDC PRO 36V control platform, the operator includes programmable functionality, integrated battery backup, solar compatibility, soft start/stop operation, and a built-in loop detector rack for advanced commercial access control installations. Integrated battery backup capability provides uninterrupted operation during power outages while maintaining support for connected gate accessories and access control devices.
Additional features include a mechanical foot pedal release for emergency manual operation and rugged continuous-duty construction designed for harsh outdoor environments. The SL-175DC PRO is UL325 2018 compliant and engineered for dependable operation in temperatures ranging from -40°F to 160°F.
Specifications:
- Model: SL-175DC PRO
- Product Type: Heavy-Duty DC Slide Gate Operator
- Manufacturer: All-O-Matic
- UL325 Compliant: 2018 Standard
- Maximum Gate Weight:
- 8,000 lbs. at 12 in./sec
- 3,000 lbs. at 24 in./sec
- Maximum Gate Length: 100 ft.
- Motor Type: 36VDC Brushless Motor
- Duty Cycle: Continuous Duty
- Gate Speed:
- 12 in. per second
- 24 in. per second
- Speed specified at time of order
- Input Power: 115/230/480VAC Single Phase
- Solar Compatible: Yes, 36VDC Solar Panel Compatible
- Battery Backup: Integrated
- Included Batteries: (3) 14Ah 12VDC Batteries
- Battery Backup Capacity: Up to 100 Cycles on a 3,000 lb. Gate
- Gearbox Ratio: 30:1 with Internal Clutch
- Emergency Release: Mechanical Foot Pedal Release
- Temperature Range: -40°F to 160°F
- Belt Size: 4L-370 (AX35)
- Main Sprocket Size: 40B18X1-3/8
- Chain Included: 50NP Chain (30 ft. Included)
- Limit Shaft Sprocket: 40B18X5/8
- Gearbox Pulley: 2AK49X3/4
- Motor Pulley: 2AK30X5/8
- Breaker Requirement: 20 Amp Dedicated Circuit
- Dimensions: 19.5 in. W × 20 in. L × 27.5 in. H
- Shipping Weight: 320 lbs.
- Warranty: 5-Year Commercial
Key Features:
- Ultra heavy-duty industrial DC slide gate operator
- Handles gates up to 8,000 lbs. and 100 ft. long
- Advanced 36VDC brushless motor technology
- Available 12 in./sec or 24 in./sec gate speed configurations
- Smooth, quiet, high-torque brushless motor operation
- Super-duty high-strength frame construction
- Heavy-duty gearbox with internal clutch
- ALL-BLDC PRO 36V advanced control board platform
- Integrated battery backup for uninterrupted operation during power outages
- Solar-ready DC power compatibility
- Built-in loop detector rack included
- Mechanical foot pedal release for emergency manual operation
- Soft start/stop functionality reduces gate wear
- Continuous-duty performance capability
- Designed for high-cycle industrial and commercial applications
- UL325 2018 compliant safety design
- Wide operating temperature range for harsh environments
Compatible Applications:
Applications include:
- Industrial slide gate systems
- High-security perimeter access control
- Transportation and logistics facilities
- Utility and infrastructure sites
- Warehouse and distribution centers
- Heavy commercial gate applications
- Gated industrial compounds
- High-cycle access control systems
- Solar-powered gate operator systems
