The All-O-Matic MACH-PRIME Dual Swing Gate Operator is a complete dual-gate automation system designed for residential swing gate applications requiring smooth operation, dependable performance, and a clean installation. Featuring dual column-mount operators, integrated battery backup, and solar-ready technology, the MACH-PRIME provides convenient automated access while maintaining a compact, low-profile appearance.
Designed for dual swing gates with leaves up to 500 lbs. and 8 feet in length per gate, the MACH-PRIME utilizes reliable 24VDC gearhead motors for quiet and consistent operation. The advanced control board offers programmable logic functions and an integrated charge controller optimized for solar applications, supporting both 12V and 24V solar panels up to 80 watts.
Integrated battery backup helps keep gates operational during power outages, while the dual-operator configuration provides synchronized opening and closing for estate entrances, residential driveways, private roads, and gated properties.
Key Features
- Complete dual swing gate operator system
- Includes operators for dual gate applications
- Supports gates up to 500 lbs. per leaf
- Maximum gate length of 8 ft. per leaf
- Quiet and smooth gate operation
- Integrated battery backup system
- Solar compatible with 12V and 24V solar panels
- Advanced programmable control board
- Built-in charge controller for solar applications
- Manual keyed release for emergency operation
- UL 325 Compliant
- Ideal for residential driveway and estate gate applications
Specifications
- Motor: 24VDC Gearhead Motors
- Maximum Gate Weight: 500 lbs. per Gate Leaf
- Maximum Gate Length: 8 ft. per Gate Leaf
- Opening Speed: Adjustable 14–25 Seconds per 90° Opening
- Power Input: 115/230 VAC Single Phase
- Solar Compatible: Yes (12V/24V Solar up to 80 Watts)
- Duty Cycle: 30 Minutes (Intermittent)
- Battery Backup: Integrated (2) 7Ah 12V Batteries
- Battery Capacity: Up to 250 Cycles
- Temperature Range: -20°F to 160°F
- Operator Dimensions: 5" D x 15" L x 15.75" H
- Control Box Dimensions: 16.75" H x 19.69" L x 7.88" D
Warranty
- 3-Year Residential Warranty
Applications
- Residential driveway gates
- Estate entrances
- Dual swing gate systems
- Private roads and ranch entrances
- HOA and community entrances
- Column-mounted gate installations
The All-O-Matic MACH-PRIME Dual Swing Gate Operator delivers reliable dual-gate automation with battery backup, solar compatibility, and smooth operation, making it an ideal solution for residential properties seeking dependable access control and enhanced curb appeal.
