Description
SLD Tech ST-30P-24 is a compact, high‑efficiency solar panel designed for 24V DC off‑grid systems. Built for reliability, it’s ideal for RVs, marine applications, telecommunications, lighting, and safety installations where dependable solar power is essential.
- Module Type: ST-30P-24
- Maximum Power: 30W
- Voltage at Pmax: 34.74V
- Current at Pmax: 0.87A
- Open-Circuit Voltage: 40.07V
- Short-Circuit Current: 0.91A
- Module Efficiency: 20%
- Cell Type: Monocrystalline silicon
- Cell Configuration: 60 cells (4×15)
- Module Dimensions: 570mm × 360mm × 30mm (22.44in × 14.17in × 1.18in)
- Weight: 2.54 kg
- Frame & Build: Durable aluminum frame, thick back plate, specialized junction box
- Maximum System Voltage: 1000V DC
- Temperature Coefficients: Voc −80±10 mV/°C; Isc −0.065±0.015%/°C; Power −0.5±0.05%/°C
- NOCT: 47±2°C
- Power Tolerance: ±5%
- Warranty: 5-year materials/workmanship; 10-year ≥90% of rated power; 25-year ≥80% of rated power
- Applications: Off‑grid installations including RVs, marine vessels, lighting and safety systems, telecommunications, and other 24V/12V DC setups
This panel is designed to deliver reliable energy in challenging conditions. Its 20% module efficiency means solid power output for its compact size, while the aluminum frame and robust back plate offer enduring performance in windy, salty, or temperature‑fluctuating environments. The 24V DC orientation makes it well suited for charging 24V battery banks or for use with appropriate charge controllers in mixed off‑grid setups. The solid warranty further protects your investment, ensuring long‑term energy supply for remote or mobile applications.
